Heat shrinkable tubes with adhesive lining
Industrial hot air blower
HUPshrink41DW-A double-walled 4:1 with adhesive lining
Radiation cross-linked polyolefin, self extinguishing according to MV SS 302,
flexible, universally applicable, Dielectric strength: 15 - 25 KV/mm according to
DIN 53481, shrinking temperature > 80° C, continuous operating temperature
- 45° C to 110° C, 1.2m packaged in a polybag, double-walled, with adhesive
lining
Industrial hot air blower
for heat shrinkable tubes
Electronic hot air blower with continuous temperature control and two blower
levels, characterised by low weight and slim design. This makes it ideal for
long and fatigue-free working and for use in difficult to access areas. The
temperature control is continous, and the air volume can be set to two different
levels. For heat shrinkable tubes.
Technical data:
Length/Ø (at shock protection): 325 mm / 85 mm
Voltage: 230 V / 50 Hz (special voltages possible)
Power: 2000 W
Temperature: 100° - 600° C continuous control
Air volume: min. 300 l/min. / max. 500 l/min.
Art. no.
kg PU
262097
0,773 1
Art. no.
kg PU
267460
0,013 1
267462
0,017 1
267464
0,030 1
267466
0,051 1
267468
0,103 1
267470
0,120 1
267472
0,183 1
m
Ø before
Ø after
1,2 4:1
4,0
1,0
1,2 4:1
8,0
2,0
1,2 4:1 12,0
3,0
1,2 4:1 16,0
4,0
1,2 4:1 24,0
6,0
1,2 4:1 32,0
8,0
1,2 4:1 52,0
13,0
