317
Machinery screws, cylinder screws
Art. no.
kg
PE PU
790470
0,001 100 100
Tin screws, assembly screws
TwinSpeed self tapping screw
galvanised, pan head, Philips cross-head and double helix thread, considerably
shortened screw-in times when compared to traditional screws thanks to the
double start thread. Uses: Wood, plywood, plasterboard, rawlplugs
Art. no.
kg
PE PU
790303
0,001 100 100
790311
0,002 100 100
790325
0,001 100 100
790326
0,001 100 100
790327
0,001 100 100
790329
0,002 100 100
790332
0,002 100 100
790333
0,003 100 100
790334
0,003 100 100
790335
0,005 100 100
TL
Ø
drive
19 3,5 Phillips PH
2
32 3,5 Phillips PH
2
13 4,2 Phillips PH
2
16 4,2 Phillips PH
2
19 4,2 Phillips PH
2
25 4,2 Phillips PH
2
31 4,2 Phillips PH
2
38 4,2 Phillips PH
2
45 4,2 Phillips PH
2
65 4,2 Phillips PH
2
Plate screw DIN 7504
in accordance with DIN 7504M (formerly N), self-tapping, hardened steel,
galvanised, pan head with Phillips slot, plate screw thread according to
DIN 7970
Art. no.
kg
PE PU
790411
0,001 100 200
790413
0,001 100 200
790416
0,001 100 200
790417
0,002 100 200
790419
0,002 100 200
790422
0,002 100 200
790423
0,002 100 200
790424
0,002 100 200
790426
0,002 100 200
790428
0,002 100 200
790432
0,002 100 200
790433
0,003 100 200
790434
0,003 100 200
790436
0,003 100 200
TL
Ø
drive
13 3,5 Phillips PH
2
19 3,5 Phillips PH
2
13 3,9 Phillips PH
2
16 3,9 Phillips PH
2
25 3,9 Phillips PH
2
13 4,2 Phillips PH
2
16 4,2 Phillips PH
2
19 4,2 Phillips PH
2
25 4,2 Phillips PH
2
32 4,2 Phillips PH
2
13 4,8 Phillips PH
2
16 4,8 Phillips PH
2
19 4,8 Phillips PH
2
25 4,8 Phillips PH
2
Plate screw DIN 7504, Tx
in accordance with DIN 7504M (formerly N), self-tapping, hardened steel,
galvanised, Tx, plate screw thread according to DIN 7970
Art. no.
kg
PE PU
790510
0,002 100 100
790512
0,002 100 100
790514
0,002 100 100
790516
0,002 100 100
TL
Ø
drive
13 4,2
Torx
20
16 4,2
Torx
20
19 4,2
Torx
20
25 4,2
Torx
20
Mounting screws
galvanised with washer, Philips cross-head, self-cutting
Art. no.
kg
PE PU
790450
0,001 100 100
790452
0,002 100 100
790454
0,002 100 100
790456
0,003 100 100
TL
Ø
drive
13 4,2 Phillips PH
2
25 4,2 Phillips PH
2
31 4,2 Phillips PH
2
45 4,2 Phillips PH
2
Mounting screws
self-cutting and self-boring, galvanised with washer, Tx
Art. no.
kg
PE PU
790500
0,001 100 100
790502
0,002 100 100
790504
0,002 100 100
TL
Ø
drive
13 4,2
Torx
20
19 4,2
Torx
20
25 4,2
Torx
20
Mounting screws
self-cutting and self-boring, galvanised with washer, Philips cross-head
TL
Ø
drive
13 4,2 Phillips PH
2
Hexagonal machine screws
according to DIN 933, continuous thread, galvanised, 8.8 quality
Art. no.
kg
PE PU
790540
0,006 100 100
790542
0,007 100 100
790544
0,008 100 100
790562
0,012 100 100
790564
0,014 100 100
790566
0,016 100 100
790588
0,023 100 100
790592
0,028 100 100
790616
0,040 100 50
790618
0,047 100 50
TL
Ø
WS
20 M6
10
25 M6
10
30 M6
10
20 M8
10
25 M8
10
30 M8
10
20 M10
10
30 M10
10
30 M12
10
40 M12
10
Socket cup screw DIN 84 Form A
in accordance with ISO 1207, EN 21207 or DIN 84, Form A, with slit, made of
hardened steel, galvanised, 4.8 quality
Art. no.
kg
PE PU
790806
0,001 100 200
790808
0,001 100 200
790832
0,002 100 200
790834
0,002 100 200
790837
0,003 100 200
790862
0,003 100 200
790864
0,004 100 200
790867
0,005 100 200
790882
0,005 100 200
790884
0,055 100 200
790888
0,007 100 200
TL
Ø
drive
16 M3
slot 5,5x0,8
20 M3
slot 5,5x0,8
16 M4
slot
7,0x1,2
20 M4
slot
7,0x1,2
30 M4
slot
7,0x1,2
16 M5
slot 8,5x1,2
20 M5
slot 8,5x1,2
30 M5
slot 8,5x1,2
16 M6
slot 10,0x1,6
20 M6
slot 10,0x1,6
30 M6
slot 10,0x1,6
Machine screw counter sunk
continuous thread, zinc-plated, pan headed Pozidriv
Art. no.
kg
PE PU
790700
0,001 100 100
790702
0,001 100 100
790704
0,002 100 100
790706
0,002 100 100
790710
0,002 100 100
790712
0,003 100 100
790714
0,003 100 100
790716
0,004 100 100
790721
0,004 100 100
790722
0,004 100 100
790724
0,005 100 100
790726
0,007 100 100
TL
Ø
drive
20 M3 Pozidriv PZ
2
30 M3 Pozidriv PZ
2
40 M3 Pozidriv PZ
2
50 M3 Pozidriv PZ
2
20 M4 Pozidriv PZ
2
30 M4 Pozidriv PZ
2
40 M4 Pozidriv PZ
2
50 M4 Pozidriv PZ
2
25 M5 Pozidriv PZ
2
30 M5 Pozidriv PZ
2
40 M5 Pozidriv PZ
2
50 M5 Pozidriv PZ
2
