168
PU Packing unit PE Price unit
The legend for abbreviations for all table headers can be found sorted alphabetically on page 408.
RoHS
Cable ties, accessories
Releasable cable ties for frequent opening and closing
for temporary wiring and sub-assembly, material: polyamide 6,6 - colour black,
operation temperature: -40° to +85° C, UL E 341152
Art. no.
kg/100 PU PE
262140
0,201 100 100
262142
0,249 100 100
262144
0,349 100 100
TL width
150 7,6 35 22
200 7,6 50 22
300 7,6 80 22
Double-locking-cable ties
material: nylon - colour black, (262710 Nylon 12).
Benefits:
• Flat head geometry
• Exterior
• Smooth side is up against the insulation - no dents or damages
• Wide contact surface protects the cable loom from damages
Application:
• Bundling of tubes in narrow shafts
• Cable bundling in hollow wall spaces
• Pull-out forces are well distributed thanks to the extra-wide tie
Art. no.
kg/100 PU PE
262700
0,319 100 100
262702
0,512 100 100
262704
0,629 100 100
262710
0,463 100 100
TL width
180 9,0 45 55
300 9,0 88 55
360 9,0 100 55
300 9,0 88 55
Cable ties with fixing eye
material: nylon, colour transparent, quick and simple to fix by hand or
with tensioning tools, extremely resistant to sea water, oil, grease, etc.,
manufactured in accordance with UL and MIL specification requirements, - 40°
C bis 85° C
Art. no.
kg/100 PU PE
262820
0,044 100 100
262822
0,100 100 100
262824
0,105 100 100
262826
0,133 100 100
262828
0,224 100 100
262830
0,443 100 100
262832
0,276 100 100
262834
0,595 100 100
TL width
Ø
100 2,5 3,0 25 8
170 3,7 4,8 40 18
170 3,7 4,0 40 18
205 4,2 4,6 60 22
300 4,8 4,8 85 22
300 7,8 6,0 80 55
370 4,8 4,9 102 22
398 7,9 6,1 122 55
Cable ties with marking space
These cable ties are suitable for simple labelling and simultaneous bundling
ofcable loops. This saves one work step. Material: nylon, colour natural, can be
fastened quickly and easily using a tool or by hand. Extremely resistant to sea
water, oil, fats etc, manufactured according to UL gema tested nylon.
Technical data: material polyamide 6.6 (N66), operating temperature -40 to
+85 C.
Group features: HF (non-halogen), RoHS-conform
Art. no.
kg/100 PU PE
262840
0,049 100 100
262842
0,093 100 100
262844
0,058 100 100
262846
0,147 100 100
262848
0,128 100 100
262850
0,198 100 100
TL width label
1 100 2,5 25 x 8 25 8
4 130 2,5 28 x 20 25 8
2 110 2,5 25 x 8 25 8
3 200 4,6 28 x 13 50 22
1 200 2,5 30 x 15 50 8
3 270 4,6 28 x 13 75 22
