Crimp connectors
Compression joints acc. to DIN 46267 Part 1 (for non-tension connections)
•
Material: 99.9% E-Cu DIN 40500
•
Surface: bare
•
With marks for correct crimping
•
Annealed material for easier crimping
Art. no.
kg/100
PU
291520
0,300 1600 100
CSS
Id.
d1 d4 v1 v2 TL
6
5 3,8 5,5 2 -
30
291522
0,600 1000 100
10
6 4,5 6,0 2 -
30
291524
1,450 300 50
16
8 5,5 8,5 2 1 50
291526
1,700 300 50
25
10 7,0 10,0 2 1 50
291528
3,100 200 50
35
12 8,2 12,5 2 1 50
291530
4,400 100 25
50
14 10,0 14,5 3 1 55
291532
5,300 100 25
70
16 11,5 16,5 3 1 55
291534
8,400 50 15
95
18 13,5 19,0 4 2 70
291536
9,600 50 25
120
20 15,5 21,0 4 2 70
291538
14,500 30 15
150
22 17,0 23,5 4 2 80
291540
16,200 30 5
185
25 19,0 25,5 4 2 85
291542
22,400 20 10
240
28 21,5 29,0 5 2 90
291544
29,500 10 5
300
32 24,5 32,0 - 2 100
291546
72,500 6 8
400
38 27,5 38,5 - 3 150
291548
85,600 8 5
500
42 31,0 42,0 - 3 160
291550
79,900 6 1
625
44 34,5 44,0 - 3 160
291552
151,000 6 1
800
52 40,0 52,0 - 3 200
291554
198,000 6 1
1000
58 44,0 58,0 - 3 1000
Compression joints acc. to DIN 48085, Part 1 (for full-tension cable connections)
•
Material: 99.9% E-Cu DIN 40500
•
Surface: bare
•
With marks for correct crimping
•
Annealed material for easier crimping
•
For full-tension cable connectiones, overhead line construction
Art. no.
kg/100
PU
291440
1,200
50
CSS
Id.
d1 d4 v1 v2 TL
6
6 3,8 6,5 8 -
65
291442
2,800
50
10
8 4,5 8,5 10 -
80
291444
2,300
50
16
8 5,5 8,5 10 -
95
291446
2,600
50
25
10 7,0 10,0 10 -
95
291448
5,800
25
35
12 8,2 12,5 10 -
95
291450
7,000
25
50
14 10,0 14,5 10 -
110
291452
9,000
25
70
16 11,5 16,5 10 -
110
291454
8,600
10
95
20 13,5 21,0 16 8 145
291456
29,200
10
120
22 15,0 23,5 16 8 160
291458
117,100
10
150
25 16,5 25,5 16,
8 180
291460
17,000
5
185
32 18,5 31,5 - 10 260
291462
163,700
5
240
34 21,0 34,5 - 12 310
291464
29,200
5
300
38 23,5 38,5 - 14 360
