Tubular terminals, standard series
Tubular terminals, standard series
•
For stranded round shaped conductors e.g. VDE 0295 class 2
•
For preround sector shaped conuctors
•
Annealed material for easier crimping
•
Material: 99.9% electrolytic copper E-CU DIN 40500
•
Surface: tin-plated
•
Vibration and shock proofing DIN EN 61373:1999-11, Cat. 1, Cl. B
available with and without sight hole e.g. 29 00 04/S (add xx xx xx/s when ordering)
Art. no.
kg/100
PU
290004
6,300 20 15
290006
6,200 80 15
290008
6,100 80 15
290009
5,900 72 18
290010
6,200 60 15
290012
7,900 60 15
CSS
M d2 d1 d4 A v1 v2
l
B c1 c2
120
8 8,5 15,0 19,5 26,0 2 1 51,0 28,0 14,0 14,0
10 10,5 15,0 19,5 26,0 2 1 51,0 28,0 14,0 14,0
12 13,0 15,0 19,5 26,0 2 1 51,0 28,0 14,0 14,0
14 15,0 15,0 19,5 26,0 2 1 52,0 28,0 15,0 15,0
16 17,0 15,0 19,5 26,0 2 1 54,0 30,0 16,0 16,0
20 21,0 15,0 19,5 26,0 2 1 63,0 36,0 22,0 22,0
290014
7,500 60 15
290016
7,300 60 15
290017
7,900 60 15
290018
7,500 60 15
290020
8,800 48 12
150
10 10,5 16,5 21,0 30,0 2 1 56,0 31,0 14,0 14,0
12 13,0 16,5 21,0 30,0 2 1 57,0 31,0 15,0 15,0
14 15,0 16,5 21,0 30,0 2 1 57,0 31,0 15,0 15,0
16 17,0 16,5 21,0 30,0 2 1 58,0 31,0 16,0 16,0
20 21,0 16,5 21,0 30,0 2 1 66,0 36,0 22,0 22,0
290022
11,100 40 20
290023
11,800 40 20
290024
10,700 40 20
290026
10,700 40 20
185
12 13,0 19,0 24,0 30,0 2 1 65,0 35,0 18,0 18,0
14 15,0 19,0 24,0 30,0 2 1 65,0 35,0 18,0 18,0
16 17,0 19,0 24,0 30,0 2 1 65,0 35,0 18,0 18,0
20 21,0 19,0 24,0 30,0 2 1 69,0 39,0 22,0 22,0
290028
13,700 30 15
290029
13,400 30 15
290030
13,400 30 15
240
12 13,0 21,0 26,0 35,0 4 2 72,0 39,0 21,5 19,0
14 15,0 21,0 26,0 35,0 4 2 72,0 39,0 21,5 19,0
16 17,0 21,0 26,0 35,0 4 2 72,0 39,0 21,5 19,0
290034
22,000 16 8
290036
21,700 16 8
290038
21,300 16 8
290040
21,400 16 8
300
12 13,0 23,5 29,5 44,0 4 2 87,0 43,0 24,0 24,0
14 15,0 23,5 29,5 44,0 4 2 87,0 43,0 24,0 24,0
16 17,0 23,5 29,5 44,0 4 2 87,0 43,0 24,0 24,0
20 21,0 23,5 29,5 44,0 4 2 87,0 43,0 24,0 24,0
290046
31,800 10 5
290048
30,500 10 5
400
16 17,0 27,0 34,0 44,0 4 2 90,0 49,0 24,0 24,0
20 21,0 27,0 34,0 44,0 4 2 90,0 49,0 24,0 24,0
290041
45,000 12 6
290043
45,000 12 6
500
16 17,0 31,0 38,0 70,0 4 2 103,0 55,0 24,0 24,0
20 21,0 31,0 38,0 70,0 4 2 103,0 55,0 24,0 24,0
290045
49,200 6 3
290047
49,200 6 3
625
16 17,0 34,0 41,0 70,0 4 2 108,0 60,0 24,0 24,0
20 21,0 34,0 41,0 70,0 4 2 108,0 60,0 24,0 24,0
Angled tubular cable lugs 90°, standard series
•
For stranded round shaped conductors e.g. VDE 0295 class 2
•
For preround sector shaped conuctors
•
Annealed material for easier crimping
•
Material: 99.9% electrolytic copper E-CU DIN 40500
•
Surface: tin-plated
Art. no.
kg/100
PU
290932/90
0,475 1800 100
290934/90
0,400 1400 100
290936/90
0,500 1400 100
CSS
M d2 d1 d4 A v1 v2
l
B c1 c2
6
5 5,3 3,5 6,5 9,0 1 -
21,0 10,0 6,5 7,5
6 6,5 3,5 6,5 9,0 1 -
21,0 12,0 6,5 7,5
8 8,5 3,5 6,5 9,0 1 -
23,0 15,0 10,0 10,0
290938/90
0,400 1000 100
290940/90
50,000 1000 100
290942/90
0,540 800 100
290944/90
0,573 600 100
10
5 5,3 4,5 7,0 10,0 1 -
22,0 12,0 6,5 7,5
6 6,5 4,5 7,0 10,0 1 -
22,0 12,0 6,5 7,5
8 8,5 4,5 7,0 10,0 1 -
25,0 15,0 10,0 10,0
10 10,5 4,5 7,0 10,0 1 -
27,0 17,0 12,0 12,0
290948/90
0,800 600 100
290950/90
0,700 600 100
290952/90
0,800 400 100
290954/90
0,950 400 100
290956/90
1,000 400 100
16
5 5,3 5,5 8,5 13,0 1 1 26,0 12,0 5,5 6,5
6 6,5 5,5 8,5 13,0 1 1 27,0 12,0 6,25 7,5
8 8,5 5,5 8,5 13,0 1 1 29,0 15,0 8,5 9,5
10 10,5 5,5 8,5 13,0 1 1 31,0 17,0 10,5 11,5
12 13,0 5,5 8,5 13,0 1 1 33,0 19,0 12,0 13,0
290958/90
1,100 400 50
290960/90
1,200 400 50
290962/90
1,250 300 50
290964/90
1,300 300 50
25
6 6,5 7,0 10,0 15,0 2 1 30,0 14,0 7,5 7,5
8 8,5 7,0 10,0 15,0 2 1 32,0 16,0 10,0 10,0
10 10,5 7,0 10,0 15,0 2 1 34,0 18,0 12,0 12,0
12 13,0 7,0 10,0 15,0 2 1 35,0 19,0 13,0 13,0
