Tubular terminals and connectors, standard series
Tubular terminals, Light „T“ series
•
tubular
•
Material: 99.9% electrolytic copper E-CU DIN 40500
•
Surface: tin-plated
•
with sight hole
Art. no.
kg/100
PU
294150
13,300 30 10
294152
13,000 30 10
294154
15,000 30 10
CSS
M d2 d1 d4 A TL
240
12 13,2 21,2 26,4 37,0 90,0
14 14,5 21,2 26,4 37,0 90,0
16 16,5 21,2 26,4 37,0 90,0
294160
15,400 16 8
294162
15,000 16 8
294164
2,900 16 8
300
12 13,2 23,4 28,6 40,0 96,0
14 14,5 23,4 28,6 40,0 96,0
16 16,5 23,4 28,6 40,0 96,0
294174
22,700 10 5
294176
22,000 10 5
400
16 16,5 26,8 32,8 37,0 104,7
20 21,0 26,8 32,8 37,0 104,7
294184
42,000 8 3
500
16 16,5 29,8 38,4 46,5 115,5
294196
66,800 6 3
630
20 21,0 34,5 44,7 50,0 133,0
Butt connectors, Light „M“ series
•
Material: 99.9% electrolytic copper E-CU DIN 40500
•
Surface: tin-plated
•
annealing for easier crimping
•
for stranded conductors e.g. VDE 0295 class 2
•
with buttmarks for precise cable insertion
Art. no.
kg/100
PU
294200
0,080 2000 200
CSS
d1 d4 TL
1,5
2,4 4,0 22,0
294202
0,080 2000 200
2,5
2,7 4,3 22,0
294204
0,300 1000 100
4
3,1 4,8 25,0
294206
0,300 1000 100
6
3,8 5,5 25,0
294208
0,400 600 100
10
4,7 6,9 25,0
294210
0,500 500 100
16
5,6 7,8 29,0
294212
0,700 200 50
25
7,1 9,5 29,0
294214
1,200 200 50
35
8,2 11,0 35,0
294218
1,400 100 40
50
9,5 12,5 35,0
294220
2,700 50 20
70
11,5 15,0 45,0
294222
3,200 50 20
95
13,5 17,0 47,0
294224
5,500 50 20
120
15,6 20,0 52,0
294226
6,500 50 20
150
16,5 21,0 59,0
294228
9,200 36 20
185
18,4 23,6 65,0
294230
11,900 12 10
240
21,2 26,4 75,0
294232
14,500 6 5
300
23,4 28,6 90,0
294234
24,200 6 5
400
26,8 32,8 106,0
