Voltage testers
Art. no.
kg PU
103826
0,264 1
TMA
3-1000
Art. no.
kg PU
103824
0,264 1
TMA
6-1000
Voltage tester “Profi LCDplus II”
Voltage tester “Profi LEDplus II”
The “Profi LCDplus II” is the new top model in our tried and tested professional
series. The innovative two-pole voltage tester is characterised by a wide
performance spectrum and practical one-handed operation. It enables testing
without finger contact and, thanks to the high CAT IV 1000 V safety level, is
suitable with immediate effect for taking measurements on hybrid and electrical
vehicles as well as for photovoltaic systems.
Functions and benefits
• Highest CAT IV 1000 V safety level
• Large, illuminated LCD
• Voltage display up to 1000 V AC and 1400 V DC
• Resistance measurement up to 1999 Ω
• Frequency display up to 1000 Hz
Technical data
„Profi LCDplus II“
Display:
Optical, LCD
Measuring range:
Automatic
Over-voltage category:
CAT IV 1,000 V
Dimensions:
300 x 75 x 20 mm
Weight:
270 g
Colour:
Red/black
Scope of delivery:
Including batteries
Accessories (optional):
Carry bag
Voltage range:
3–1000 V AC (TRMS/RMS)
4–1400 V DC
Throughput check:
0–200 Ω with acoustic signal
Phase display:
> 100 V AC
Voltage supply:
2 x 1.5 V AAA (display of voltages is
possible even without batteries)
Polarity:
Yes (- in LCD)
PELV display:
Optical, acoustic and vibrating
Protection class:
IP 65
Standard:
EN 61243-3:2010
Resistance measurement:
1–1999 Ω
Frequency measurement:
0-500 Hz
Data-hold:
Voltage and resistance
Automatic power off function:
Yes
FI/RCD test:
30 mA at 230 V AC using two buttons
Single-pole phase test:
Yes
Two-pole phase-sequence test: Yes
Illumination of measuring point: White LED
4-mm test tip adapter:
Can be unscrewed
Guarantee:
5 years
The new two-pole voltage tester “Profi LEDplus II” is the result of consistent
further development of our popular “Profi LEDplus”. It is characterised by user-
friendly handling, robust and safe construction and meets all the requirements a
specialist user makes of the modern voltage tester. Thanks to the highest safety
level, CAT IV 1000 V, it is also suitable for measurements on hybrid and electrical
vehicles as well as photovoltaic systems.
Functions and benefits
• Highest CAT IV 1000 V safety level
• Practical one-handed operation
• Robust, safe construction format
• Tests without finger contact
• Display on voltages even without battery
Technical data
„Profi LEDplus II“
Display:
Optical, LEDs
Measuring range:
Automatic
Over-voltage category:
CAT IV 1,000 V
Dimensions:
300 x 75 x 20 mm
Weight:
270 g
Colour:
Red/black
Scope of delivery:
Including batteries
Accessories (optional):
Carry bag
Voltage range:
6–1000 V AC
6–1400 V DC
Throughput check:
0–50 kΩ optical/acoustic
Phase display:
> 100 V AC
Voltage supply:
2 x 1.5 V AAA (display of voltages is possible
even without batteries)
Diode test:
Yes
Polarity:
Yes (+,- LED)
PELV display:
Optical, acoustic and vibrating
Protection class:
IP 65
Standard:
EN 61243-3:2010
Automatic power off function:
Yes
FI/RCD test:
30 mA at 230 V AC using two buttons
Single-pole phase test:
Yes
Two-pole phase-sequence test: Yes
Illumination of measuring point: White LED
4-mm test tip adapter:
Can be unscrewed
Guarantee:
5 years
