Voltage testers
Art. no.
kg PU
103811
0,433 1
Art. no.
kg PU
100666
0,139 1
“Multi Check II” - digital high-capacity multimeter
The “Multi Check II” is particularly safe to use. Thanks to the automatic measuring
range protection, it is impossible to operate incorrectly. In addition, the digital
multimeter has an easy to read LC display with background illumination.
Functions and benefits
• Automatic measuring range protection
• Large LCD with background lighting
• Temperature measurement
Technical data
„Multi Check II“
Display:
37 mm, large, illuminated LCD
Over-voltage category:
CAT III 600 V
Weight:
380g including batteries.
Scope of delivery:
Including measuring cables, holster,
temperature sensor and battery
Voltage supply:
1x 9 V 6LR61
Diode test:
Yes
Standard:
IEC/EN 61010-1, IEC/EN 61010-2-033
Dimension:
200 x 89 x 38 mm
AC voltage:
2 V, 20 V, 200 V ; ±1.0 %, ±5 Digits
600 V ; ±1.2 %, ±5 Digits
AC current:
2 mA, 20 mA ; ±1.0 %, ±5 digits
200 mA ; ±1.5 %, ±3 digits
10 A ; ±2.0 %, ±8 digits
Operating temperature range: 0–40 °C (32–104 °F)
DC voltage:
200 mV, 2 V, 20 V, 200 V ; ±0.5 %, ±3 digits
600 V ; ±0.8 %, ±5 digits
DC current:
2 mA, 20 mA ; ±1.0 %, ±3 digits
200 mA ; ±1.5 %, ±3 digits
10 A ; ±2.0 %, ±5 digits
Throughput test:
Yes
Input impedance:
> 7.5 MΩ, type 10 MΩ (ACV & DCV)
Frequency measurement range: 0-20 kHz
Capacity measurement range: To 20 μF
Storage temperature range:
-10-50 °C (14-122 °F)
Maximum input voltage:
600 V AC/DC
Fuses:
200 mA (resettable)
10 A/1000 V (fast)
Temperature measurement:
-20–1000°C with K-type sensor
Alternating current bandwidth: 50-400 Hz
Resistance:
200 Ω ; ±1.0 %, ±5 digits
2 kΩ, 20 kΩ, 200 kΩ ; ±1.0 %, ±5 digits
2 MΩ ; ±1.0 %, ±5 digits
20 MΩ ; ±1.5 %, ±5 digits
Guarantee:
5 years
Circuit tester “Control”
The “Control” recognises, thanks to the no-contact voltage sensor, alternating
voltages through insulation. Defective lamps, for example, in fairy light chains
or similar will be shown quickly and precisely. The incorporated current warning
issues and alarm when life-threatening voltage is present. The electronics also
enable single-pole phase detection. Throughput tester with LED pocket torch,
without flat battery, with replaceable measuring cables.
Functions and benefits
• Reliable throughput tester
• No-contact voltage sensor
• High-performance LED torch
Technical data
„Control“
Over-voltage category:
CAT II 300 V
Dimensions:
120 x 60 x 30 mm
Weight:
90 g (without batteries)
Colour:
Red
Scope of delivery:
2 measuring cables
Accessories (optional):
Crocodile clips, carry bag
Throughput check:
Optical 0–20 Ω
acoustic 0–250 Ω
Test voltage:
4.5 V
Test current:
Optical - 10 mA
acoustic - 2 mA
External voltage protection: Up to 300 V
Guarantee:
5 years
