Wire strippers
Automatic wire stripper Super Plus
for solid and flexible conductors and strands between 0.2 and 6.0 mm² (AWG
24 - 10)
•
For fast and precise stripping even of difficult – to-access places
•
No adjustment to wire cross section necessary
•
Suitable for cables with insulation made from PVC and other materials
•
Special scanning system, therefore no damage to conductors
•
Adjustable longitudinal stop from 6.0 to 15.0 mm for even serial stripping
•
External side cutters for conductors up to 2.5 mm²
•
Body of pliers made from fibre-glass reinforced polyamide
•
Handle of pliers with elongated hole at the bottom for mounting
•
TÜV / GS tested
Art. no.
kg PU
210695
0,088 1
TL
mm²
170 0,2 - 6
210695/E
0,010 1
spare blades
Automatic wire stripper
•
For single, multiple and fine wire cables from 0.2 to 6.0 mm²
•
Ergonomic, automatic strippers
•
Increased operating comfort thanks to anti-slip soft components on the
stripper handle
•
Automatic, energy-saving scanning system
•
Cable cross-section does not need to be set
•
Optimally positioned side cutter for up to 2.5 mm²
•
Adjustable lengthwise stop 6 to 18 mm for same sleeve removal lengths
when carrying out series work
•
Exchangeable blades
•
TÜV / GS tested
Art. no.
kg PU
210696
0,151 1
TL
mm²
180 0,2 - 6
210696/2
0,030 1
spare blades
Automatic wire stripper HAUPA-Special
•
Ergonomic, automatic strippers
•
For cable from 0.5 to 6.0 mm²
•
Automatic scanning system
•
Cable cross-section does not need to be set
•
Optimally positioned side cutter for Cu wires up to Ø 2.8 mm
•
Adjustable lengthwise stop to 18 mm
•
TÜV / GS tested
Art. no.
kg PU
210681
0,179 1
TL
mm²
170 0,5 - 6
Wire stripper /
Solar
•
For cables with large cross-sections from 6.0 to 16 mm²
•
Also for stripping PVC flex 3 x 0.75 mm² or solar cables Solarflex-X PV1-F
•
Automatic strippers
•
Optical lengthwise stop to 20 mm
•
Cable cross-section does not need to be set
•
Any stripping length can be selected as needed
•
Exchangeable blades
•
TÜV / GS tested
Art. no.
kg PU
210685
0,147 1
TL
mm²
160 6 - 16
Flat cable pliers
•
For PVC insulated flat cables up to a maximum of 12 mm in width and a
cross-section of 0.75 x 2.5 mm²
•
Automatic strippers
•
Optical lengthwise stop to 20 mm
•
Strippers do not need to be set
•
Any stripping length can be selected as needed
•
Exchangeable blades
•
TÜV / GS tested
Art. no.
kg PU
210686
0,148 1
TL
mm²
160 0,75 - 2,5
