INFO
Cable strippers
Information for strippers
Stripping removes the outer sleeve of a installation cable.
For cables that have already been installed in installation sockets and
are thus difficult to access, you use a round stripper.
When stripping, open the stripper and place it on the cable in such a
way as to ensure that the round blade is position at the point of the
sleeve you wish to remove.
Turn the stripper a quarter turn to the left and to the right, bend the
cable a little, and open up the stripper.
Place the tool closer to the end of the cable, close again, and stripper
the sleeve away easily.
There is a variety of strippers available for the various types of cable.
Important:
Important, when stripping the insulation of inner wires may
not be damaged.
Cable stripper „Kabifix“
•
For cutting opening and stripping cables from Ø 6 - 25 mm
•
Longitudinal and round cut (swivel lever)
•
Ø 6 – 28 mm
•
NYY 4 – 16 mm²
•
NYM 5 – 16 mm²
•
Coaxial and bell round cable
•
Isoflex and PVC piping maximum Ø 25 mm
•
Interior adjustment screw for adjusting the cutting depth
•
Exchangeable blades
Art. no.
kg PU
200022
0,096 1
Ø
6 - 28
200024
0,010 1
6 - 28
spare blades
Cable stripper „Kabifix LWL”
•
For cutting opening and stripping fibre-optic and coaxial cables from
Ø 6 - 25 mm
•
Longitudinal and round cut (swivel lever)
•
Interior adjustment screw for adjusting the cutting depth
•
Exchangeable blades
Art. no.
kg PU
200023
0,136 1
Ø
6 - 25
200023/M
0,003 1
6 - 25
spare blades
Cable stripping knive
•
For removing the sleeve from all current round cables
•
Blades, titanium nitride coated, thanks to the higher cutting speed
•
Lower wear, increased durability
•
Cutting depth can be adjusted using the setting screw on the end of the
handle
•
Automatic adjustment to round and lengthwise cuts
•
Handle security thanks to soft component insert on the bar and handle
•
Titanium nitride coated replacement blade in the housing
•
Housing made from high-quality, hard wearing polyamide
•
With titanium nitride coated hook blade
•
TÜV / GS tested
Art. no.
kg PU
200031
0,100 1
Ø
8 - 28
200046
0,004 1
spare blades
Cable stripping knive
•
For removing the sleeve from all current round cables
•
Blades, titanium nitride coated, thanks to the higher cutting speed
•
Lower wear, increased durability
•
Cutting depth can be adjusted using the setting screw on the end of the
handle
•
Automatic adjustment to round and lengthwise cuts
•
Handle security thanks to soft component insert on the bar and handle
•
Titanium nitride coated replacement blade in the housing
•
Housing made from high-quality, hard wearing polyamide
•
TÜV / GS tested
Art. no.
kg PU
200038
0,090 1
Ø
4 - 16
200040
0,091 1
8 - 28
200042
0,101 1
28 - 35
200044
0,108 1
35 - 50
200046
0,004 1
35 - 50
Spare blades
Stripper „All-rounder“
•
Cable stripper for round cables from Ø 4 - 15 mm and flat cables up to
15 mm width
•
Stripping 1.5 - 2.5 mm² single wire
•
Lengthwise cut
Art. no.
kg PU
200050
0,111 1
Ø
4 - 15
Stripper standard
•
For removing the sleeve from all current round cables
•
Blades, titanium nitride coated, thanks to the higher cutting speed
•
Lower wear, increased durability
•
No need to set blades required to cutting depth
•
Fixture clip for safe storage
•
Housing made from high-quality, hard wearing polyamide
•
TÜV / GS tested
Art. no.
kg PU
200036
0,065 1
Ø
8 - 13
Universal stripper
•
Stripper for removing the sleeve from all current round cables Ø 8 to 13 mm
•
Removing the insulation on various cable types, e.g. NYM 3 x 1.5 mm² to
5 x 2.5 mm²
•
Contoured blades for stripping wires 0.2-0.3-0.8-1.5-2.5-4.0 mm²
•
Ideal for working in distribution and junction boxes
•
Longer cable lengths can be stripped using the lengthwise cutting
mechanism
•
Safe hold thanks to the inclusion of anti-slip handle zones
•
No need to set blades required to cutting depth
•
Additional titanium nitride coated retractable blade
•
TÜV / GS tested
Art. no.
kg PU
200043
0,063 1
Ø
0,2 - 4,0
