...convincing solutions
13
INFO
Cable cutters
Precise cut!
The blade joints (screw connection on rotation blade) are adjusted to
0.05 mm!
Durable and strong
Serrations on the blade and the transport handle are milled!
The contact pressure is thus lower than for cast teeth.
200124, 200126:
•
One-handed cable cutter
•
Lever joint bolts, thickness 6.5 mm.
•
16 mm Full material, milled knee lever.
•
Transport handle play can be set (2 grub screws 3 mm in lever)
Front cable cutter
for Copper and Alu-cable 25 mm Ø, squeeze-free cutting, optimized lever-
transmission
Art. no.
200124
mm²
Ø
Cu/Al wire multi wiring
120
Cu/Al wire sector format
120
Cu wire fine wiring
120
Cu wire fine wiring or
telecommunication cable
25
25
25
25
Cutting range:
Length:
245
Weight:
1,020
Front cable cutter
for Copper and Alu-cable 34 mm Ø, squeeze-free cutting, optimized lever-
transmission by eccentric drive system
Art. no.
200126
mm²
Ø
Cu/Al wire multi wiring
185
Cu/Al wire sector format
240
Cu wire fine wiring
240
Cu wire fine wiring or
telecommunication cable
34
34
34
34
Cutting range:
Length:
330
Weight:
1,541
Front cable cutter with eccentric drive
Very easy to use precision one-handed front cutter, excellent crush-free cutting
quality even with fine wired cables, tried and tested and almost wear-free
offset drive, rotation blade can be locked in any position, cutting range up to a
diameter of 35 mm.
•
One-handed cable cutter
•
Dual needle-bearing offset lever 14 mm
•
Particularly easy to move, thanks to reduction of friction on joint
•
Considerable reduction of manual force
•
Lever joint bolts, thickness 8 mm
•
For the toughest of usage conditions
•
Locking with a locking shaft
•
Accidental opening of handles in tool case is prevented
•
Transport handle play is fixed
Art. no.
200131
mm²
Ø
Cu/Al wire multi wiring
240
Cu/Al wire sector format
240
Cu wire fine wiring
300
Cu wire fine wiring or
telecommunication cable
35
35
35
35
Cutting range:
Length:
330
Weight:
1,673
Front cable cutter with eccentric drive
Easy to use two-handed front cutter with patented offset drive, excellent crush-
free cutting quality even for large cross-sections, rotation blade can be locked
in any position, cutting range up to a diameter of 55 mm.
•
Two-handed cable cutter for armoured steel cable
•
Dual needle-bearing offset lever 14 mm
•
Particularly easy to move, thanks to reduction of friction on joint
•
Considerable reduction of manual force
•
Lever joint bolts, thickness 12 mm
•
Extremely well reinforced version for particularly tough uses
•
Locking with a locking shaft
•
Accidental opening of handles is prevented
•
Integrated toothed comb for cleaning in handle
Art. no.
200151
mm²
Ø
Cu/Al wire multi wiring
550
Cu/Al wire sector format
550
Cu wire fine wiring
550
Cu wire fine wiring or
telecommunication cable
55
55
55
55
Cutting range:
Length:
485
Weight:
3,493
Front cable cutters with eccentric drive
