6
PU Packing unit PE Price unit
The legend for abbreviations for all table headers can be found sorted alphabetically on page 408.
wire rope
armoured steel cable
(SWA)
ACSR
BOLT
solid
steel
solid
CU
single wire
multi-wire
sector-shaped
fine wire
communication
Cable cutters
Cable cutter
•
for cutting copper/aluminium cables, fine wire, multiple-core and solid copper
•
Chrome vanadium steel, dip-insulated handles
•
insulating function in upper head area
•
Cable measuring function thanks to the 180 degree crossover of the legs
•
not for solid conductors
•
Data, telephone and control cable, maximum Ø 8 mm
•
Cu single wire, maximum 16 mm²
•
Cu fine wire, maximum 16 mm²
•
Cu multi-wire, maximum 16 mm²
•
Al single wire, maximum 16 mm²
•
Al multi-wire, maximum Ø 8 mm = 16 mm²
Art. no.
kg PU
201085
0,177 1
TL
Ø mm²
160
8 16
Cable cutter
•
for cutting copper/aluminium cables, fine wire, multiple-core and solid copper
•
Chrome vanadium steel, dip-insulated handles
•
insulating function in upper head area
•
Cable measuring function thanks to the 180 degree crossover of the legs
•
not for solid conductors
•
Data, telephone and control cable, maximum Ø 12 mm
•
Cu single wire, maximum 16 mm²
•
Cu fine wire, maximum 35 mm²
•
Cu multi-wire, maximum 25 mm²
•
Al single wire, maximum 25 mm²
•
Al multi-wire, maximum Ø 8 mm = 25 mm²
Art. no.
kg PU
201087
0,289 1
TL
Ø mm²
200
12 35
Cable cutter
•
for cutting copper/aluminium cables, fine wire, multiple-core and solid copper
•
Chrome vanadium steel, plug-on handles
•
insulating function in upper head area
•
Cable measuring function thanks to the 180 degree crossover of the legs
•
not for solid conductors
•
Data, telephone and control cable, maximum Ø 8 mm
•
Cu single wire, maximum 16 mm²
•
Cu fine wire, maximum 16 mm²
•
Cu multi-wire, maximum 16 mm²
•
Al single wire, maximum 16 mm²
•
Al multi-wire, maximum Ø 8 mm = 16 mm²
Art. no.
kg PU
201086
0,216 1
TL
Ø mm²
180
8 16
Cable cutter
•
for cutting copper/aluminium cables, fine wire, multiple-core and solid copper
•
Chrome vanadium steel, plug-on handles
•
insulating function in upper head area
•
Cable measuring function thanks to the 180 degree crossover of the legs
•
not for solid conductors
•
Data, telephone and control cable, maximum Ø 12 mm)
•
Cu single wire, maximum 16 mm²
•
Cu fine wire, maximum 35 mm²
•
Cu multi-wire, maximum 25 mm²
•
Al single wire, maximum 25 mm²
•
Al multi-wire, maximum Ø 8 mm = 25 mm²
Art. no.
kg PU
201088
0,361 1
TL
Ø mm²
240
12 35
Cable cutters with spring joint
•
for cutting Cu/Al cables, fine and multi-wiring
•
not suitable for steel wire and wire rope
•
Chrome vanadium steel
•
self-opening joint spring
•
enormous cutting power with reduced force expenditure
•
not for solid conductors
Art. no.
kg PU
200086
0,266 1
200088
0,475 1
TL
Ø mm²
170
10 25
230
15 70
Cable cutter
for cutting Cu/Al cables.
•
Data, telephone and control cable, maximum Ø 25 mm
•
Cu single wire, maximum 16 mm²
•
Cu fine wire, maximum 70 mm²
•
Cu multi-wire, maximum 25 mm²
Art. no.
kg PU
200105
0,281 1
TL
Ø mm²
215
20 70
