Germany:
HAUPA
, Koenigstr. 165-169, 42853 Remscheid, Phone: +49 (0)2191 8418-0, Fax: +49 (0)2191 8418-840,
...convincing solutions
9
Video 200183
Video 200112
Cable cutters
Hand cable cutter
ratchet action type, with spare blade, for copper and alu cable
Art. no.
200089
mm²
Ø
Cu/Al wire multi wiring
185
Cu/Al wire sector format
185
Cu wire fine wiring
240
Cu wire fine wiring or
telecommunication cable
32
32
32
32
Cutting range:
Length:
230
Weight:
0,615
Hand cable cutter
ratchet action type, with spare blade, for copper and alu cable
Art. no.
200183
mm²
Ø
Cu/Al wire multi wiring
400
Cu/Al wire sector format
240
Cu wire fine wiring
450
Cu wire fine wiring or
telecommunication cable
52
52
52
Cutting range:
Length:
280
Weight:
0,914
Ratchet two handed cable cutter
„SCAR45“ for SWA cable
Cutting capacity: Steel reinforced Cu-Al cables up to Ø 45 mm maximum
Art. no.
200199
Ø
Steel reinforced Cu-Al cables
45
Cutting range:
Length:
430
Weight:
1,700
INFO
Cable cutters
Precise cut!
The blade joints (screw connection on rotation blade) are adjusted to
0.05 mm!
Durable and strong
Serrations on the blade and the transport handle are milled!
The contact pressure is thus lower than for cast teeth.
200111, 200112:
•
One-handed cable cutter
•
Lever joint bolts, thickness 6.5 mm
•
16 mm Full material, milled knee lever
Cable cutter
Handy one-hand device with smooth-running and robust drive technology up to
34 mm Ø, all moveable parts made from hardened steel
Art. no.
200111
mm²
Ø
Cu/Al wire multi wiring
185
Cu/Al wire sector format
240
Cu wire fine wiring
240
Cu wire fine wiring or
telecommunication cable
34
34
34
34
Cutting range:
Length:
250
Weight:
0,790
Cable cutter
Handy one- and two-hand tool with smooth-running and robust drive
technology up to 52 mm Ø, all moving parts made from hardened steel
Art. no.
200112
mm²
Ø
Cu/Al wire multi wiring
400
Cu/Al wire sector format
400
Cu wire fine wiring
450
Cu wire fine wiring or
telecommunication cable
52
52
52
52
Cutting range:
Length:
320
Weight:
1,122
