Crimping pliers for Photovoltaik
INFO
Photovoltaik
The photovoltaic energy conversion is carried out with the assistance
of solar cells that are connected in order to form solar modules in
photovoltaic plants. The generated electricity can be stored on site in
accumulators or fed into the power network. If the energy is fed into
the public power network then the direct current generated by the solar
cells with be converted by a converter into alternating current. In order
to constantly make energy available, the energy must be stored.
Crimping pliers
with locking device, with adjustable crimp pressure, chrome plated
square
crimp (MC 3), roll crimp (MC 4)
Art. no.
kg PU
211657
0,560 1
211659
0,560 1
mm²
2,5 - 6
MC3
2,5 - 6
MC4
Crimpset „MULTI Photovoltaik“
Innovative crimping tool with rapid change system - one tool for almost all
crimping applications
Contents of set:
Crimping plier Multi (211962)
Crimping dies for „Multi - Contact“ connectors MC3
2,5 + 4 + 6 mm², AWG 13/11/10
Crimping dies for „Multi - Contact“ connectors MC4
2,5 + 4 + 6 mm², AWG 13/11/10
Other advantages:
•
Screw less fast change system for crimping
dies
•
Single hand operation with expenditure
energy
•
With ratchet and built-in safety release,
guarantees proper electrical connection
•
Adjustable crimp pressure
•
Chrome plated tool frame
•
Additional purchase of other crimping
dies possible
•
Handy box protects pliers and dies
Art. no.
kg PU
212005
1,150 1
width height
depth
260 40
200 MC3 + MC4
Crimping pliers HUPstar Photovoltaic
for photovoltaic connectors. Crimp pliers for industrial users, revolving
precision impression dies with parallel feed, changeable dies.
Pressing star 213084/E
Photovoltaics:
Amphenol Helios H4: 2.5 / 2.5 / 6, Multi-Contact MC3: 2.5 / 2.5 / 6
Multi-Contact MC4: 2.5 / 2.5 / 6, Tyco Solarlok: 1.5 / 1.5 / 4.6
Art. no.
kg PU
213084
0,650 1
213084/E
0,160 1
TL
mm²
230
1,5 - 6
dies
1,5 - 6
HAUPA Crimp System for Photovoltaics
Crimp System Pliers for Photovoltaics
The basic hardware of the carrying case consists of:
•
one pair of pliers, chromium-plated without crimping pliers insert
•
one allen wrench (A/F 2.5 mm)
•
one open-jawed wrench (A/F 7)
•
2 pieces spare screws (M4 x 10/M4 x 16 mm)
Specificationen:
•
Special crimping pliers for crimping solar contacts of almost all types of
connector systems
•
Guaranteed exact, solder-free, electric connections
•
Parallel closing of the crimping dies
•
30 % reduction of hand force through optimized leverage
•
Forced latching for reliable crimping, releasable
•
Crimp pressure adjustable
•
Long lever arm allowing single-hand and two-hand control
•
Easy change of the crimping pliers inserts, Locator fitting option for the
determination of the connector position
•
Several crimping positions in one crimp die assembly
•
Design: chromium-plated with black plastic handle
•
Material: specially heat-treated special steel
Art. no.
kg PU
212200
0,998 1
mm²
6
6 pcs.
Crimp inserts for "Huber & Suhner" contacts
212206 2,5 + 4 mm², AWG 13/11
1
212208 4 + 6 mm², AWG 13/11
1
Crimp inserts for "multi-contact" contacts
212210 MC3, 2,5 + 4 + 6 mm², AWG 13/11/10
1
212212 MC3, Locator
1
Crimp inserts for "multi-contact" contacts
212214 MC4, 2,5 + 4 + 6 mm², AWG 13/11/10
1
212216 MC4, Locator
1
Crimp insert for "Hirschmann" contacts
212218 2,5 + 4 + 6 mm², AWG 13/11/10
1
Crimp insert for "Tyco" contacts
212220 Tyco 1,5 + 2,5 + 4 + 6 mm²
1
212222 Locator for Tyco
1
Dies for Solar contacts Amphenol
212226 2,5 + 4 mm², AWG 13/11
1
212228 2,5 + 4 mm², AWG 13/11
1
