INFO
Crimp stars for open and closed tool frames
Crimping pliers HUPstar from HAUPA
When it comes to high-end crimping technology for professional, industrial
users, with the HUPstar HAUPA has succeeded in introducing a range which
uses 3 different frame types to handle all common connection pressings
simply by quickly and reliably replace the relevant star. Thus making it the ideal
complete tool for your tool case and in the workshop.
7 versions of HUPstar are already permanent components of the range:
1. End sleeves
Insulated crimp-style cable lugs
Ring cable lugs (DIN 46234 / DIN 46341)
2. End sleeves 0.14 – 16 mm²
Open brass cable lugs
3. Coaxial:
4. Photovoltaics / Solar
5. Fibre Optic Connector
6. Twisted contacts, square
7. Automotive contacts
The star can be changed in just 30 seconds!
The colour code on the stars enables fast and correct assignment.
The extremely precise parallel feed and the eroded precision crimp profile
mean that this product has been very well received by the industry. Not just
thanks to the high quality processing of the crimp star which is, thanks to the
surface properties, TÜV guaranteed for around 80,000 precision crimps.
After all a precise and safe normed crimp is the guarantee for complication-
free, high quality and long-lasting connections.
Ergonomically, the HUPstar can, thanks to the short construction of the
handles and the rather small opening angle, also be operated quickly, safely
and gentle to joints even with small hands.
Due to the innovative manufacturing procedure, individual stars, designed for
industrial customers, can also be made without additional costs.
Multi-function pliers
Tool frame „HUPstar” – closed
Tool frame without star crimp, closed design for all of the following pressing
stars
Art. no.
kg PU
213077
0,400 1
Tool frame „HUPstar” – open
Tool frame without star crimp, open design specifically for connectors
Art. no.
kg PU
213078
0,510 1
Video HUPstar
