INFO
Mechanical crimping pliers for tubular cable lugs
Mechanical crimping tool characterised by its compact design. It is possible
to make crimps even in confined working conditions, where conventional large
tools cannot be used.
The mature construction of the drive has proven its reliability many times over
in practice. In this manual crimping tool very little wear can be seen even after
many years of use, this is decisive for the reliable repetition of the required
crimping depth. After all, today’s highly stressed crimped connections only
comply with safety regulations when the required electrical and mechanical
values are achieved over long periods.
Another safety aspect is that the crimping tool can only be detached from the
crimped lug when the required crimping depth has been reached. By turning
the wheel on the handle in an anti-clockwise direction the crimping inset can
be set in position on the lug. Only then does the actual crimping process begin
with the one-hand lever.
The quality of the crimped connection is dependent on the choice of cable lug,
the crimp inset and the correct choice of cable cross section.
Crimping pliers
one hand precise tool, with ratchet and built-in-force-blocking device, crimping
pressure 20 kN, interchangeable dies, easy to remove from the crimped lug by
opening the crimping head, special small design for working in small areas
Product-specific features
•
outstanding manageability
•
compact construction
•
precision drive
•
fast forward feed
•
can be used anywhere
Art. no.
kg PU
215000
1,531 1
mm²
6 - 50
Metal box
for storing of crimping pliers and dies
Art. no.
kg PU
215002
0,934 1
Crimping dies
for standard cable lugs and compacted cables, suitable for compacted cables
WM pressing
Art. no.
kg PU
215004
0,041 1
215006
0,040 1
215008
0,037 1
215010
0,036 1
215012
0,033 1
mm²
10
16
25
35
50
Crimping dies
for crimping terminals DIN,
hexagon pressing
Art. no.
kg PU
215030
0,100 1
215032
0,100 1
215034
0,100 1
215036
0,150 1
215038
0,150 1
215040
0,150 1
Cu
Al
Id.
6
-
5
10
-
6
16
10
8
25
16
10
35
25
12
50
35
14
Crimping dies
noninsulated crimping terminals,
mandrel shape pressing
, DIN 46234
Art. no.
kg PU
215014
0,018 1
215016
0,190 1
215018
0,190 1
215020
0,190 1
215022
0,020 1
215024
0,020 1
mm²
6
10
16
25
35
6 - 35
Crimping dies
noninsulated crimping terminals,
mandrel shape pressing
, DIN 46234
Art. no.
kg PU
215026
0,039 1
215028
0,039 1
mm²
10
16
Crimping dies
for end sleeves,
trapezoid pressing
Art. no.
kg PU
215042
0,150 1
215044
0,150 1
215046
0,150 1
215048
0,200 1
215050
0,200 1
mm²
6
10
16
25
35
