Hydraulic crimping tools
Hydraulic hand pliers „HO-6“
Crimping head can be rotated by 180°, manual return after completed
pressing, light and compact construction in black plastic case, without dies.
•
Pressing force in kN: 60
•
Working pressure in bar: 700
•
Head can be opened
•
Opening / Hub: 17 mm
•
Pressing width: slim
•
Cable lugs: standard Cu 6-300
•
DIN Cu 6-300
•
DIN Al 16-240
•
Connectors: standard Cu 6-300
•
DIN Cu 6-300
•
DIN Al 16-240
•
Dual-piston pump
•
Weight in kg: 3,5
•
Weight of set in kg: 5,0
Art. no.
kg PU
216802
5,000 1
mm²
dimension
6 - 300 500 x 170 x 80 mm
Hand pliers „MO-6“ for exchangeable dies
Extent of supply:
1 crimping tool, in metal suitcase.
•
Crimping range cable lugs: Cu 6-300
•
DIN Cu 6-300 / DIN Al 16-240
•
Crimping range connectors: Cu 6-300
•
DIN Cu 6-300 / DIN Al 16-240
Art. no.
kg PU
216804
11,800 1
mm²
dimension
10 - 300
765 x 175 mm
Crimping headstock „KO-6“
in plastic case, without dies.
•
Pressing force in kN: 60
•
Working pressure in bar: 700
•
Head can be opened
•
Opening/ Hub: 17 mm
•
Pressing width: slim
•
Cable lugs: standard Cu 6-300
•
DIN Cu 6-300
•
DIN Al 16-240
•
Connectors: standard Cu 6-300
•
DIN Cu 6-300
•
DIN Al 16-240
•
Quick coupling
•
Weight in kg: 3,2
•
Weight of set in kg: 4,2
Art. no.
kg PU
216807
4,200 1
mm²
dimension
6 - 300 235 x 91,5 x 57 mm
Dies for terminals and connectors standard
Art. no.
kg PU
216806
0,136 1
216808
0,12 1
216810
0,136 1
216812
0,135 1
216814
0,135 1
216816
0,134 1
216818
0,132 1
216820
0,132 1
216822
0,130 1
216824
0,128 1
216826
0,125 1
216828
0,121 1
216830
0,118 1
mm²
PW
6
5
10
5
16
5
25
5
35
5
50
5
70
5
95
5
120
5
150
5
185
5
240
5
300
5
Dies for terminals and connectors DIN
Art. no.
kg PU
216832
0,123 1
216834
0,122 1
216836
0,125 1
216838
0,120 1
216840
0,120 1
216842
0,119 1
216844
0,120 1
216846
0,120 1
216848
0,120 1
216850
0,120 1
216852
0,120 1
216854
0,115 1
216856
0,120 1
Cu
Al
Id.
PW
6
-
5
5
10
-
6
5
16
-
8
5
25
-
10
5
35 16 - 25
12
5
50
35
14
5
70
50
16
5
95
70
18
5
120
-
20
5
150 95 - 120
22
5
185
150
25
5
240
185
28
5
300
240
32
5
