Hydraulic crimping tools
Battery powered crimping tool „SD400-6“
Crimping head can be rotated by 360°, manual return flow after perfect
pressure, mandrel shape pressing.
Extent of supply:
1 crimping tool, 1 charger, 1 battery, 1 strap, in SysCon
stacking box „SysCon M“ 220372.
•
Pressing force in kN: 60
•
Working pressure in bar: 700
•
Head can be opened
•
Cable lugs: standard Cu 25-400
•
Connectors: standard Cu 25-400
•
Pressing time, battery-operated in sec.: 6-12
•
Battery charging time in min.: 30
•
Battery type: Li-Ion, 18 V, 1,5 Ah
•
Weight in kg: 2,4
•
Weight of set in kg: 7,9
Art. no.
kg PU
216667
7,900 1
mm²
dimension
25-400
455 x 75 mm
Battery powered crimping tool „SD400-6M“
Technical data and scope of delivery, see 216667.
With the different colours of the sensor LED, it shows whether the pressing has
been completed successfully or which errors have occurred:
Light is green: Pressing completed as standard, motor stopped.
Light is orange: Battery voltage not sufficient
Light is red: Pressing interrupted before completed
The device also has 1 white LED designed to illuminate the working area.
Art. no.
kg PU
216667/M
7,900 1
mm²
dimension
25-400
455 x 75 mm
Test pin
Test pin for hydraulic four mandrel pressing tools
Art. no.
kg PU
216660/B
0,566 1
Hydraulic hand pliers „HD400-6“
Crimping head can be rotated by 360°, manual return after completed
pressing, light and compact construction in black plastic case.
•
Pressing force in kN: 60
•
Working pressure in bar: 700
•
Head can be opened
•
Cable lugs: standard Cu 25-400
•
Connectors: standard Cu 25-400
•
Dual-piston pump
•
Weight in kg: 5,2
•
Weight of set in kg: 6,7
Art. no.
kg PU
216661
6,700 1
mm²
dimension
25-400 585 x 160 x 75 mm
Crimping headstock „HKD400“
in plastic case.
•
Pressing force in kN: 60
•
Working pressure in bar: 700
•
Head can be opened
•
Cable lugs: standard Cu 25-400
•
Connectors: standard Cu 25-400
•
Quick coupling
•
Weight in kg: 3
•
Weight of set in kg: 4
Art. no.
kg PU
216666
4,000 1
mm²
dimension
400 375 x 343 x 75 mm
Template for four mandrel pressing
Template for hydraulic four mandrel pressing tools
Art. no.
kg PU
216660/L
0,566 1
