Pumps for hydraulic crimping headstocks
Hydraulic foot pump „F-700“
material: aluminium alloy, light design, twin-cam pump, automatic switching
from closing (ca. 25 ccm/Hub) to working feed rate (ca. 2.5 ccm/Hub), security
valve, max. working pressure 700 bar (+ 10/- 30 bar), without hose,
with quick
coupling
Art. no.
kg PU
216348
12,000 1
NP
700
Hydraulic high-pressure hose
steel-reinforced with rapid coupling to foot pump art. 216348 and electro-
hydraulic pump art. 216352
Art. no.
kg PU
216238
0,950 1
216240
1,100 1
216242
1,600 1
216244
2,000 1
m
2
3
4
5
Electro-hydraulic pump „PN700 l“
electric foot switch, completely self-acting, also the release of the dies at the
end of the operation, 2 m high pressure tube and hydraulic connectors, for
industrial uses, where a high level of production is needed, 230 volt, with foot
switch control, pump for working outside
Art. no.
kg PU
216352
20,000 1
216358
20,000 1
NP
700
230V
700 Akku/230V
Battery-hydraulic pump „PA-700“
2 stage hydraulics, manual control switch, manual return flow after perfect
pressure, LED for battery control, 1 quick charger, 1 battery Li-Ion, 3 Ah,
carrying belt, max. operating pressure: 700 bar with 1,8 m hose,
with quick
coupling
.
With the different colours of the sensor LED, it shows whether the pressing has
been completed successfully or which errors have occurred:
Light is green: Pressing completed as standard, motor stopped.
Light is orange: Battery voltage not sufficient
Light is red: Pressing interrupted before completed
Cutting/Pressing/Punching
Art. no.
kg PU
216357
8,000 1
NP
700 Bat./230V
