Hydraulic crimping headstocks
Hydraulic crimping headstock „KH-25“
for uninsulated terminals 95 - 630 mm², pressure 250 kN, for crimping dies
hexagon shape according to DIN 48083 page 3 and 4.
•
Pressing force in kN: 250
•
Working pressure in bar: 700
•
Opening/ Hub:Pin
•
Pressing width: wide
•
Pressing area Cu/Al: 95-630
•
Dual-piston pump
•
Quick coupling
•
Weight in kg: 6,4
•
Weight of set in kg: 9
Art. no.
kg PU
216236
9,000 1
TL
mm²
185 95 - 630
Crimping dies DIN-connection, Cu/Al
hexagon pressing
dies according DIN 48083 page 4 suitable for DIN-
connection material according to DIN. Cu ze (free of tensile)
Art. no.
kg PU
212372
1,340 1
212376
1,340 1
212380
1,335 1
212382
1,325 1
212384
1,250 1
212388
1,275 1
212390
1,180 1
212392
1,160 1
212394
1,110 1
212396
1,100 1
mm²
Al
Id.
95 70 18
120
-
20
150 95-120 22
185 150 25
240 185 28
300 240 32
300 300 34
400 400 38
-
-
42
625 500 44
Crimping dies, standard, Cu
standard,
hexagonal pressing
Art. no.
kg PU
212580
1,340 1
212581
1,340 1
212582
1,335 1
212583
1,325 1
212584
1,250 1
212585
1,275 1
212586
1,160 1
212587
1,110 1
212588
1,100 1
Cu
95
120
150
185
240
300
400
500
625
Hydraulic crimping headstock set
Content:
Art. No. 216236 Hydraulic crimping headstock, Art. No. 216238
Hydraulic high-pressure hose, 2 m, Art. No. 216348 Hydraulic foot pump, Art.
No. 216251 Carrycase.
•
Pressing force in kN: 250
•
Working pressure in bar: 700
•
Opening/ Hub: Pin
•
Pressing width: wide
•
Pressing area Cu/Al: 95-630
•
Dual-piston pump
•
Quick coupling
•
Weight in kg: 18,4
•
Weight of set in kg: 21
Art. no.
kg PU
216250
21,000 1
mm²
95 - 630
