* Only HAUPA batteries can be charged.
Hydraulic crimping tools
Battery powered crimping tool „SDE240-6“
Crimping head can be rotated by 180°, with fast opening, return manually once
compressing is complete, no inserts required, mandrel shape pressing.
Extent of supply:
1 crimping tool, 1 charger, 1 battery, 1 strap, in SysCon
stacking box.
•
Pressing force in kN: 60
•
Working pressure in bar: 700
•
Pressing width: thorn
•
Cable lugs: standard Cu 10-240
•
Connectors: standard Cu 10-240
•
Pressing time, battery-operated in sec.: 6-12
•
Battery charging time in min.: 30
•
Battery type: Li-Ion, 18 V, 1,5 Ah
•
Weight in kg: 2,4
•
Weight of set in kg: 7,9
Art. no.
kg PU
216669
7,900 1
mm²
dimension
10 - 240
455 x 75 mm
Battery powered crimping tool „SDE240-6M“
Technical data and scope of delivery, see 216669.
With the different colours of the sensor LED, it shows whether the pressing has
been completed successfully or which errors have occurred:
Light is green: Pressing completed as standard, motor stopped.
Light is orange: Battery voltage not sufficient
Light is red: Pressing interrupted before completed
The device also has 1 white LED designed to illuminate the working area.
Art. no.
kg PU
216669/M
7,900 1
mm²
dimension
10 - 240
455 x 75 mm
Accessories
Battery Li-Ion 18 V
for all 18 Volt Li-Ion battery tools
Art. no.
kg PU
215503
0,859 1
Battery Li-Ion 18 V, 3 Ah
for all 18 Volt Li-Ion battery tools
Art. no.
kg PU
215511
0,859 1
* Quick charger Li-Ion 18 V
for all 18 Volt Li-Ion battery tools
Art. no.
kg PU
215513
0,819 1
Hydraulic oil
0,5 l
Art. no.
kg PU
216254
1,000 1
