Hydraulic crimping headstock + cylinder „KH-45“
for terminals and butt connectors to 1000 mm², together with an adapter it
is possible to use all other crimping dies of the other crimping headstock,
low weight in comparison to the crimping range, excellent price relation, snap
head, extensionable system to bend and punch electric bus bars socket-joint
connection.
•
Pressing force in kN: 450
•
Working pressure in bar: 700
•
Pressing width: wide
•
Pressing area Cu/Al: 120-1000
•
Quick coupling
•
Weight of set in kg: 13,5
Art. no.
kg PU
216355
13,500 1
TL
mm²
185 120 - 1000
Crimping dies, standard
standard,
hexagon pressing
for crimping terminals and connectors
DIN 46235 and for Al terminals and
Al connectors
Art. no.
kg PU
216304
2,635 1
216306
2,600 1
216308
2,620 1
216310
2,580 1
216312
2,580 1
216314
2,235 1
216316
2,300 1
216318
2,300 1
mm²
120
150
185
240
300
400
500
625
Crimping dies, DIN
DIN,
hexagon pressing
for terminals and connectors DIN 46235 and for Al
terminals and Al connectors
Art. no.
kg PU
216320
2,635 1
216322
2,600 1
216324
2,620 1
216326
2,580 1
216328
2,580 1
216330
2,380 1
216332
2,325 1
216334
2,300 1
216336
2,300 1
216338
2,300 1
216340
2,040 1
mm²
Al
Id.
120
-
20
150 95-120 22
185 150 25
240 185 28
300 240 32
300 300 34
400
-
38
500
-
42
625
-
44
800
-
52
1000
-
58
