Hydraulic crimping tools
Battery powered crimping tool „S0-6“
Hydraulic for interchangeable dies, crimping head can be rotated by 180°,
Head can be opened, manual return flow after perfect pressure.
Extent of supply:
1 crimping tool, 1 charger, 1 battery, 1 strap, in SysCon
stacking box „SysCon M“ 220372 without dies.
•
Pressing force in kN: 60 kN
•
Working pressure in bar: 700
•
Head can be opened
•
Opening/ Hub: 17 mm
•
Pressing width: slim
•
Pressing time, battery-operated in seconds: ca. 5
•
Battery charging time in minutes: 30
•
Battery type: Li-Ion, 18 V, 1,5 Ah
•
Cable lugs: standard Cu 6-300
•
DIN Cu 6-300
•
DIN Al 16-240
•
Connectors: Cu 6-300
•
DIN Cu 6-300
•
DIN Al 16-240
Art. no.
kg PU
216801
7,900 1
mm²
dimension
6 - 300
383 x 75 mm
Battery powered crimping tool „S0-6M“
Technical data and scope of delivery, see 216801.
With the different colours of the sensor LED, it shows whether the pressing has
been completed successfully or which errors have occurred:
Light is green: Pressing completed as standard, motor stopped.
Light is orange: Battery voltage not sufficient
Light is red: Pressing interrupted before completed
The device also has 1 white LED designed to illuminate the working area.
Art. no.
kg PU
216801/M
7,900 1
mm²
dimension
6 - 300
383 x 75 mm
Battery powered crimping tool „AO-6“
2 step hydraulic for replaceable pressing dies, crimping head can be rotated
by 180°, can be opened, with quick opening, manual return after completed
pressing, LED to check battery status.
Included in delivery:
1 crimping tool, 1 charger, 1 battery, 1 carry strap, in
plastic case, without dies.
•
Pressing force in kN: 60
•
Working pressure in bar: 700
•
Opening/ Hub: 17 mm
•
Head can be opened
•
Pressing width: slim
•
Cable lugs: standrad Cu 6-300
•
DIN Cu 6-300
•
DIN Al 16-240
•
Connectors: standard Cu 6-300
•
DIN Cu 6-300
•
DIN Al 16-240
•
Pressing time, battery-operated in seconds: 4
•
Battery charging time in minutes: 60
•
Battery type: Li-Ion 18 V, 3 Ah
•
Dual-piston pump
•
Weight in kg: 4,5
•
Weight of set in kg: 9,5
With the different colours of the sensor LED, it shows whether the pressing has
been completed successfully or which errors have occurred:
Light is green: Pressing completed as standard, motor stopped.
Light is orange: Battery voltage not sufficient
Light is red: Pressing interrupted before completed
The device also has 2 white LED designed to illuminate the working area.
Art. no.
kg PU
216800
9,500 1
mm²
dimension
6 - 300 375 x 343 x 75 mm
