Deep
Indent
End sleeves
TWIN end sleeves
Insulated crimp-style
cable lugs
Insulated shrink connectors
non-insulated cable lugs
Socket sleeves (female)
Socket sleeves (female)
with cable stop
Coaxial connectors
for twisted contacts and
connectors
for rolled contacts and
connectors
for D-Sub connectors
Multi-contact M3
for Photovoltaics
Multi-contact M4
for Photovoltaics
Amphenol
for Photovoltaics
Tyco-Solar
for Photovoltaics
Connectors for
modular connectors
Stewart connectors for
modular connectors
Hirose connectors for modular
connectors
non-insulated cable lugs
DIN 46234
non-insulated connectors
DIN 46341
standard tubular terminals
DIN tubular terminals CU
DIN tubular terminals AL
standard tubular
terminals, light
Nylon-insulated tubular
cable terminals
standard connectors CU
DIN connectors CU
DIN connectors AL
standard connectors, light
F-type
Deep indent connectors
Four thorn pressing
without inserts
Technical notes for the various pressing formats
for the pressing of cables using HAUPA cable lugs
and connectors.
The following pressing formats are available:
Hexagonal pressing
for pressing standard CU tubular terminals and
connectors, tubular terminals for switching device
connections, pressing cable lugs and connectors
DIN 46235/DIN 46267, Al pressing cable lugs
and connectors and end sleeves
Mandrel shape pressing
for pressing of standard CU tubular terminals
and connectors, tubular terminals for switching
device connections, crimp-style cable lugs DIN
46234 and pin cable lugs DIN 46230, insulated
crimp-style cable lugs, conduit terminals for
fine-wired conductors, nickel tubular terminals
and connectors
Oval pressing
for pressing of dual pressing cable lugs,
C clamps, insulated tubular terminals and
connectors, insulated pin cable lugs, press
connectors DIN 48217, insulated cable
connections
Trapezoidal pressing
for pressing of end sleeves ends and twin end
sleeves
Square pressing
for pressing of end sleeves ends and twin end
sleeves
Hexagonal pressing
for pressing of end sleeves
Square pressing
Multi-contact
Application area:
Photovoltaics, twisted contacts
Roll pressing
for pressing of brass cable lugs,
D-Sub, MC4
WM pressing
for standard cable lugs and compacted cables
Round pressing
of sector-shaped conductors 90° and 120°
Four thorn pressing
for pressing standard tubular terminals and
connectors - also on sealed conductors -
F-type tubular terminals and connectors
Light cable lugs and connectors
Tubular terminals = Switching device connections
Pictogram
cable connectors
Pictogram
press-profiles
