Germany:
HAUPA
, Koenigstr. 165-169, 42853 Remscheid, Phone: +49 (0)2191 8418-0, Fax: +49 (0)2191 8418-840,
...convincing solutions
55
INFO
Mechanical crimping pliers for tubular cable lugs
In this hand press the crimping stroke is produced by a number of hand lever
movements. The transport ratchet starts the eccentric wheel moving and
con-rods convert the eccentric turning motion into a straight-line stroke of the
guide that runs in grooves.
The bottom crimping inset is placed in the guide. It sits on an adjustment plate
that is screwed on to the guide. This plate compensates for all the tolerances
resulting from the manufacturing process or wear and tear.
By turning the wheel on the handle in an anti-clockwise direction the crimping
inset can be transported directly to the installation on the connecting part.
Only then does the actual crimping process begin with the hand lever. When
the required crimping depth has been reached the press releases the pressure
spontaneously and the hinged cover can be opened to remove the connector.
The crimping process can be interrupted if an error has been made in the
classification of the inset, cable lug or cable. To do this swing the hand lever
completely out, depress the ratchet and turn the forward feed lever backwards.
The quality of the crimped connection is dependent on the choice of cable lug,
the crimp inset and the correct choice of cable cross section.
Crimping pliers
precise tool with ratchet and built-in-force-locking device, interchangeable
dies, easy to remove from the crimped lug by opening the crimping head
Product-specific features
•
can be used anywhere
•
minimum strength required
•
broad application spectrum
•
precision drive
•
rational use
Art. no.
kg PU
215200
4,500 1
mm²
10 - 240
Metal box
for storing of crimping pliers and dies
Art. no.
kg PU
215202
3,700 1
Crimping dies
for standard cable lugs and compacted cables,
WM pressing
Art. no.
kg PU
215204
0,221 1
215206
0,320 1
215208
0,349 1
215210
0,331 1
215212
0,330 1
215201
2,486 1
215203
0,308 1
215205
0,317 1
215207
0,300 1
mm²
10 - 25
16 - 35
50
70
95
120
150
185
240
Crimping dies
for crimping terminals DIN,
hexagon pressing
Art. no.
kg PU
215230
0,350 1
215232
0,330 1
215234
0,328 1
215236
0,330 1
215238
0,326 1
215240
0,326 1
215242
0,321 1
215244
0,300 1
215246
0,305 1
215248
0,305 1
215250
0,290 1
Cu
Al
Id.
10
6
16
8
25
16
10
35
25
12
50
35
14
70
50
16
95
70
18
120
20
150 95-120
22
185
150
25
240
185
28
Crimping dies
for uninsulated crimping terminals,
mandrel shape pressing
,
DIN 46234 + DIN 46341
Art. no.
kg PU
215214
0,178 1
215216
0,169 1
215218
0,163 1
215220
0,170 1
215222
0,163 1
215224
0,161 1
215226
0,152 1
215228
0,144 1
mm²
10 - 70
95 - 150
10 - 70
16 - 35
25 - 50
95
120
150
Crimping dies
for end sleeves,
trapezoid pressing
Art. no.
kg PU
215252
0,400 1
215254
0,380 1
215256
0,381 1
215258
0,361 1
215260
0,400 1
215262
0,363 1
215264
0,401 1
mm²
16
25
35
50
70
95
120
