Germany:
HAUPA
, Koenigstr. 165-169, 42853 Remscheid, Phone: +49 (0)2191 8418-0, Fax: +49 (0)2191 8418-840,
...convincing solutions
49
Crimpsterne
HUPstar
Dies for HUPstar
HUPstar
End sleeves
0.5 – 10 mm²
Insulated cable lugs
0.1 – 6 mm²
Ring cable lugs
(DIN 46234 / DIN 46341) 0.25 – 10 mm²
Art. no.
kg PU
213086/E
0,160 1
dies
End sleeves
0.14 - 16 mm²
Socket sleeves
0,14 – 6 mm 0.14 - 6 mm
Art. no.
kg PU
213080/E
0,160 1
dies
HUPstar „Coaxial”
Coaxial
BNC, TNC, SNB, SNC, SMS, SMA, MCX, 1.07 – 10.9 mm
Art. no.
kg PU
213082/E
0,160 1
dies
HUPstar „Photovoltaic”
Photovoltaics / Solar
Amphenol Helios H4, multi-contact MC3/ MC4 2.5 - 6.0
Tyco Solarlok, 1.5 – 4.6 mm²
Art. no.
kg PU
213084/E
0,160 1
mm²
dies
1,5 - 6
HUPstar „Fibre Optic Connector”
Fibre Optic Connector
1.69; 2.5; 3; 3.25; 3.65; 4.2; 4.52; 4.95; 5; 6.5; 10.9
Art. no.
kg PU
213098/E
0,170 1
dies
HUPstar „Twisted contacts, square”
Twisted contacts, square
0.1; 0.14; 0.25; 0.34; 0.5 1; 1.5; 2.5; 4; 6; 10
Locator for Ø 1.6; 2.5; 4
Art. no.
kg PU
213102/E
0,170 1
dies
HUPstar automotive
Tool frame „HUPstar” – automotive
Tool frame without star crimp, closed design for the automotive network
Art. no.
kg PU
213079
0,300 1
HUPstar
Automotive contacts
Hirose DF1B-2428SC UL1007
Litz wire
Hirose DF1B-2428PC UL1007
Litz wire 0.08; 0.14; 0.25
Hirose DF1B-30SC UL1007
Litz wire
Hirose DF1B-30PC UL1007
Litz wire 0.05
Hirose DF1B-2022SC, Hirose DF1B-2022PC
0.34; 0.50
Art. no.
kg PU
213100/E
0,170 1
dies
CONTACT SYSTEMS
Timer Contact System: Micro Timer I, Micro Timer II, Micro Timer III,
Junior Power Timer, Standard Timer, Maxi Power Timer including Tab and
Receptacle contacts from 0.2 - 10 mm
2
APPLICATION DELPHI AUTOMOTIVE CONNECTION SYSTEMS
Ducon Series 0.8, 1.5, 2.8, 4.8, 6.3, 9.5 mm; GT 150 cable range from 0.35 - 1.00 mm.
GT 280 cable range from 0.75 - 5.00mm; Metri-Pack 150, Metri-Pack 280, Metri-Pack 480,
Metri-Pack 630, Micro 64, Micro-Pack 100, HES 1.0, HES 1.6, HES 2.4, HES 6, Molex MX64
